ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm

  • 1
  • 2
  • 3
  • 4

Brand Name : HongCe

Model Number : HCWP300

Certification : calibration certificate (cost additional)

Place of Origin : China

MOQ : 1 set

Price : Negotiatable

Payment Terms : T/T

Supply Ability : 1 set /month

Delivery Time : 40 days

Packaging Details : plywood

Product name : Water Pump Comprehensive Performance Test System

Power supply : 220V 50Hz

Rotating speed(r/min) : 0-3000rpm

Flow rate (M³/h) : 0-200M³/h

Drive Mode : Servo motor drive

Pump head(m) : 0-200m

water circulatory system : open style

Pipe diameter : 1 inch, 2 inch, 3 inch, 4 inch, total 4 lines Pipe diameter

Contact Now

Water Pump Comprehensive Performance Test System 0 - 3000 rpm

Standard:

ISO9906 Rotodynamic pumps - Hydraulic performance accetance tests - Grades 1, 2 and 3.

Application:

This pump performance comprehensive test system is a special system for pump performance testing, suitable for various test pump types; the system is mainly composed of main control cabinet, flow sensor, pressure sensor and instrument. The pump motor can be tested for voltage, current, power, flow, speed, pressure, head and other data; and can draw H-Q curve, P-Q curve, η-Q curve and (NPSH) according to the data collected by the test project. ) r-Q curve. Appliance Performance Test Lab

Parameters:

Basic parameter requirement

medium Clear water
Test pump type

Centrifugal pump

Mixed flow pump

Axial flow pump

Whirlpool pump

Screw pump

Well submersible pump

Sewage submersible pump

Small submersible pump

Fire pump

Voltage(V) 0-500V
power(KW) 200
Rotating speed(r/min) 0-3000rpm
Flow rate(M³/h) 0-200M³/h
Pump head(m) 0-200m

System Requirements

water circulatory system open style
Pipe diameter 1 inch, 2 inch, 3 inch, 4 inch, total 4 lines
Traffic regulation Electric
Shaft power flow method Electrometry
Test items Flow rate, pump total head, speed of rotation, pump power input, cavitation test
System accuracy Level 2 / Level C
Acquisition parameters AC voltage, current, power, frequency, motor speed, inlet pressure, outlet pressure, flow, etc.
Pump performance analysis and calculation of main parameters, curves Head, flow, NPSH; flow at rated head, lift at rated flow, pump measured flow deviation, head deviation, pump efficiency deviation, and so on.
Data Acquisition Analysis Mode Computer automatic collection, analysis, printing, database management

ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm

ISO9906 Water Pump Comprehensive Performance Test System 0 - 3000 Rpm
