IEC 62885 Dry Vacuum Cleaners Appliance Performance Test Lab PLC Control

Guangzhou HongCe Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment

IEC 62885 Dry Vacuum Cleaners Appliance Performance Test Lab PLC Control

  • 1
  • 2
  • 3

Brand Name : HongCe

Model Number : HCDVEF01

Certification : calibration certificate (cost additional)

Place of Origin : China

MOQ : 1 set

Price : Negotiatable

Payment Terms : T/T

Supply Ability : 1 set /month

Delivery Time : 45 days

Packaging Details : plywood

Product name : Dry Vacuum Cleaners Appliance Performance Test

Standard : IEC 60312-1, IEC 62885

application : perform the performance characteristics of Dry Vacuum Cleaners

Floor test plate : 2000*680mm

test sample : dry vacuum cleaners

Air data measuring box : 500 mm × 500 mm × 500 mm

hold-downs : 1.4 m × 0.05 m × 0.05 m and weight 10 kg

control mode : PLC control

Contact Now

IEC 62885 Dry Vacuum Cleaners Appliance Performance Test PLC Control

Standard:

IEC 60312-1 Vacuum cleaners for household use – Part 1: Dry vacuum cleaners – Methods for measuring the performance;

IEC 62885 Surface cleaning appliances – Part 2: Dry vacuum cleaners for household or similar use – Methods for measuring the performance.

Application:

This system is applicable for measurements of the performance of dry vacuum cleaners for household use in or under conditions similar to those in households. Appliance Performance Test Lab

Test items:

1. Dust removal from hard flat floors

2. Dust removal from hard floors with crevices

3. Dust removal from carpets

4. Air data

5. Energy consumption

Basic configuration:

SN Part Name Main technical parameter
1.1 Test bed European standard 5*45+45*90 aluminum profile, MISUMI aluminum profile
1.2 Automatic floor gap dust remover Oak, 2000*680; standard gap (10*3±0.05mm), aluminum rod
1.3 Automatic carpet dust remover Electrical guide rail (movable, ensuring standard testing area). Xinjie servo system for constant speed control :0.5±0.02m/s
1.4 Automatic carpet tension device Double weights technology ensures that (60-70) N tension can be distributed on the carpet uniformly
1.5 Automatic ash sprinkling device Electrical guide rail, continuous vibration ash sprinkling trough (150-360mm testing width)
1.6 Automatic ash pressing device Electrical lifting ash pressing wheel (3.8kg); with electrical guide rail and Xinjie servo for speed control. Constant speed: 0.5±0.02m/s
1.7 Automatic brush width adjustment device Electrical guide rail. With Xinjie servo system, automatic lifting and automatic width adjustment (150-360mm)
1.8 Automatic weighing Electronic scale is connected to computer software. Click to confirm without the need of copying reading manually; organic testing cover; 600* 600 scale
1.9 Automatic environment monitoring The temperature and humidity atmospheric gauge is connected to computer software. Click to confirm without the need of copying reading manually;
1.10 Computer and display 8G memory; 500G disc; 19.5 inch; XP system
1.11 Temperature and humidity atmospheric meter Accuracy: temperature ±0.5℃; humidity 3%RH; atmospheric voltage ±0.2kPa; RS485 communication
1.12 AC and DC digital power meter (including time measurement) Power consumption: P: Grade 0.5, sampling speed: 0.1s; power consumption time: 50-9999ms, maximum permissible error: 5ms. Appliance Performance Test Lab
1.13 Precision electronic balance Accuracy: 0.01g; RS232 communication
IEC 62885 Dry Vacuum Cleaners Appliance Performance Test Lab PLC Control
