IEC Testing Equipment Programmable Temperature And Humidity Chamber Climatic Test
Product introduction for IEC Testing Equipment:
This testing machine is mainly used for the adaptability test of electronic, electrical, food, automobile, rubber, plastic, metal and other products, parts and materials in high and low temperature alternating wet and hot environment storage, transportation and use.
Purpose for IEC Testing Equipment:
It is suitable for all kinds of electronic, electrical, electrical, plastic and other raw materials and devices to carry out cold resistance, heat resistance, wet resistance, dry resistance test and quality control engineering reliability test equipment;
Product feature for Temperature And Humidity Chamber:
1. Especially suitable for fiber, LCD, crystal, inductance, PCB, battery, computer, mobile phone, rubber, plastic and other products of high temperature resistance, low temperature resistance, moisture resistance cycle test;
2. The machine can simulate different environmental conditions such as high temperature and high humidity/high temperature and low humidity/low temperature and high humidity/high temperature and low temperature, with high accuracy programming control and fixed-point control system that is easy to operate and learn, to provide the best test environment.
Technical parameters for IEC Testing Equipment:
| No. | Project | Parameter |
| 1 | Temperature range | A:-20～+150℃ B:-40～+150℃ C:-70～+150℃ |
| 2 | Humidity range | 20%～98%RH |
| 3 | Temperature departure | ±2℃ |
| 4 | Temperature uniformity | ±2℃ |
| 5 | Temperature fluctuation | ±0.5℃ |
| 6 | Heating rate | Approx. 3℃/min (nonlinear, no-load) |
| 7 | Cooling Rate | Average 1.0℃/min (nonlinear, no-load) |
| 8 | Humidity deviation | ±3.0％RH(＞75％RH)；±5.0％RH(≤75％RH) |
| 9 | Humidity uniformity | ± 3.0% RH (no load) |
| 10 | Humidity fluctuation | ±2.5％RH(no load) |
| 11 | Inner box material | SUS304 stainless steel plate |
| 12 | Power supply | 220V±10%V/ 380V±10%V；50Hz； |
Product detail picture:
