IEC60335-1 Cable Testing Equipment Oxygen Bomb Air Bomb Aging Tester 2.7 - 3.3MP

IEC60335 / 4000cm³ Cable Testing Equipment Oxygen Bomb - Air Bomb Aging Tester​

Test conditions

1. The materials which have different substantially compositions should not be tested simultaneously.

2. The sample should not contact the tank wall, and the samples should not contact each other.

3. The sample volume should be less than 1/10 of the tank’s effective volume. Cable Testing Equipment

4. Oxygen should be no less than 97% purity industrial oxygen, air should be no oil, non-moist (The air compressor is supplied by the user).

Standard: IEC60335-2-6 clause 22, IEC60335-2-9 clause 22,Clause 22.32 of IEC 60335-1 Household and similar electrical appliances – Safety – Part 1: General requirements, IEC 60811-1-1 sub clause 9.1 and IEC 60811-1-2 sub clause 8.3 and etc.

Application: It is used to process the aging test for the electric wire, the insulation layer and sheath of the rubber( plastic,artificial leather) as well as other high polymer materials under the action of required pressure and temperature in the medium of oxygen and compressed air.

Test sample: Wires, cables, rubber (plastic, leather) insulation layer and sheath, as well as other polymer materials. Cable Testing Equipment

Feature: The device adopts inside and outside dual-chamber structure, the samples are suspended in an oxygen tube, filling with oxygen purity ≥ 97%, make the pressure up to 2.1 ± 0.07 MPa and maintain the temperature at 70 ° ± 1 ° C, then process aging test for 96 hours in this state. Cable Testing Equipment

Parameters:

IEC60335-1 Cable Testing Equipment

Oxygen Bomb Cable Testing Equipment

Air Bomb Aging Tester
